Blast gen5 Powercore luminaires are versitile workhorses, equally adept at floodlighting, washing, and spotlighting. In this example nine Blast Powercore, RGBW luminaires wash the front of this 160 ft long nine story hotel, drawing attention and creating a fun and inviting atmosphere.
Six Blast luminaires with 10° x 60° spread lenses are wired in two runs and mounted on the ground 20 ft from the building. From the canopy, 3 Blast luminaires uplight the center section of the hotel, including the sign at the top of the building, and working in unison with the other luminaires. Each luminaire has a 6 ft whip wired into a junction box.
Data Enabler Pro powers all of the luminaires with standard cabling from each junction box to the Data Enabler Pro in three runs. No special wiring required.
Control options
Depending on your needs, each of these controllers offer certain advantages
ColorDial Pro–A wall-mounted all-in-one PoE controller with 8 pre-programmed light shows which you can configure. These easy-to-set-up shows include fixed, variable, and random colors, and a variety of wash effects, including custom colors and chasing rainbow.
Antumbra iColor Keypad Controller–A wall-mounted all-in-one PoE controller with customizable fascia, six pushbuttons with onboard effects and configurable shows. Use the configuration software (included) to adjust the effects color, speed, and brightness, then assign the effects to any button for quick and easy playback.
