sPDS-480ca 24V

    Power/data supply for large-scale Ethernet installations

    sPDS-480ca 24V is a power/data supply designed for large-scale Ethernet LED lighting installations using low-voltage luminaires from Color Kinetics.


    • sPDS-480ca 24 V delivers 480 watts of output via eight 30-watt ports and automatically accommodates input voltages ranging from 100 VAC to 240 VAC. Short-circuit protection prevents device failure due to incorrectly wired f. The standard IEC power inlet accepts both US and international power cables.

    • Housed in a 2U rack-mountable enclosure, sPDS-480ca 24 V includes rack handle and surface-mount brackets, for versatile mounting options.

    • Environment
      Dry Location, IP20
    • With onboard controls, sPDS-480ca 24 V incorporates automatic luminaire discovery and testing, eliminating the need for additional addressing tools or software. sPDS-480ca 24 V features a backlit LCD for easy menu viewing.

    • Over-temperature detection and selectable shutdown options protect sPDS-480ca 24 V against operation beyond its rated temperature specification. Variable-speed fans keep noise levels low and include serviceable air filters.

    • Regulatory Listings
      UL/cUL, FCC Class A, CE
