    PDS-80 CK2 24V

    Power/data supply engineered for Chromacore Pro luminaires, including Flex Compact Pro and legacy luminaires such as C-Splash 2.



    The PDS-80 CK2 24V is the power/data supply for Flex Compact Pro luminaires delivering integrated power and data in a robust, IP66-rated enclosure. With up to 80 W total power output and default 3-channel control via DMX or Ethernet, it is designed to make installation fast and commissioning straightforward. A tethered cover, clearly labeled terminals, and a built-in test button simplify installation and speed up commissioning.

    • Toggle view

    Features

    • Purpose-built for Chromacore Pro luminaires
      The PDS-80 CK2 24V integrates a power supply and control module in a single rugged housing delivering up to 80 W of total power output and default 3-channel control to Flex Compact Pro luminaires. Also supports legacy luminaires such as C-Splash 2, protecting investments.

    • Fast, straightforward installation
      An IP66-rated enclosure with tethered cover and captive screws keeps everything secure and accessible. Clearly labeled terminal block connectors for DMX, Ethernet, line voltage, and luminaires take the guesswork out of wiring. Cables route through the narrow end of the housing for a clean, streamlined footprint.

    • Seamless connectivity
      Inputs and outputs for both DMX and Ethernet (KiNET and sACN) allow you to daisy-chain multiple units in series. Dual 100 MB IDC connectors and a high-speed 1 GB RJ45 connector ensure fast, reliable Ethernet connections across a wide range of networking environments.

    • Rugged housing
      Cast aluminium IP66-rated enclosure built for long-term reliability. Conduit entries accommodate NPT conduit in US trade sizes of 1/2 in (data) and 3/4 in (power), or metric sizes of M20 (data) and M25 (power).
    • Know it's working before you leave the site
      A built-in test button instantly confirms luminaire connection and triggers a color wash light show before the control system is connected. On-board indicators provide visual feedback for normal operation, DMX and Ethernet connection detection, and data transmission. Press again to resume normal operation.

    • Surge protection
      Built-in 6 kV protection guards against electrical surge transients coupled on power input side of L, N, G, keeping your installation safe and running.



    • Complete control
      Works seamlessly with the full Color Kinetics controller ecosystem including iPlayer 4, iPlayer 3, Antumbra iColor Keypad, and ColorDial Pro, as well as third-party DMX or Ethernet (KiNET, sACN) controllers. Also compatible with Interact Landmark for remote monitoring and management.
