ReachElite High Punch Powercore gen2, RGBW

    High-performance exterior long-throw floodlight with intelligent RGBW light

    ReachElite High Punch is a premium exterior long-throw luminaire designed to light large-scale outdoor structures ranging from bridges and facades to monuments and skyscrapers. Powerful enough to hit targets over 418 m (1,373 ft) away with the 300 W luminaire, ReachElite High Punch raises the bar for optical control, performance and beam quality in LED lighting. What sets ReachElite apart from the competition is its application efficiency, high punch, and adaptability. ReachElite delivers high-quality white and color light exactly where you want it. With a 3° native beam angle, ReachElite introduces a new level of precision and punch to the premium exterior LED luminaire market.

    Product Summary and Specification Sheets


    • High punch
      ReachElite's High Punch optical system enables the layering of precise high quality light. Increased application efficacy is realized as a result of high illuminance sources enabling luminaire placement at far greater distances from surfaces to be illuminated. The native 3° beam angle allows the light to hit targets up to 418 m (1,373 ft) away using the 300 W luminaire, without sacrificing light efficiency or quality.
    • Design flexibility
      ReachElite is available in three versions: 100 W, 200 W, and 300 W. Each luminaire contains either one, two, or three 100 W heads that can be aimed independently of each other. This empowers lighting designers to utilize multiple applications and beam direction in a single luminaire.

    • Flexible field-installed accessories
      Choose from a full line of high-quality accessories, from seven different spread lenses, a louver, full and half glare shields, a rock guard, and a slipfitter mount for all ReachElite luminaires. Color Kinetics accessories make project customization simple.

    • Integrates patented Powercore technology
      Patented Powercore controls power output to luminaires directly from line voltage - rapidly, efficiently, and accurately.
    • Application adaptability
      ReachElite High Punch excels in a wide range of lighting applications including spot lighting, and wall grazing. Optional secondary accessories combined with easy precise aiming bring ultimate in system flexibility to customize the look and performance of any project. Precision optical system allows for placement freedom.
    • Chromasync technology
      Improves color consistency between all LED luminaires within 2SDCM and simplifies commissioning.  The color control algorithm utilizes active temperature measurement combined with the data measured during manufacturing each array.   


    • Reliable
      ReachElite Powercore provides years of reliable use under rugged conditions. ReachElite offers more protection from corrosion by meeting ASTM B117 standard for > 1,500 hours of corrosion resistance and ANSI C136.31 with a 5G vibration rating (3G with Slipfitter mount), and elimination of water pooling on main cover lens and accessories.


    • Easily Controlled
      Works seamlessly with Color Kinetics controllers, including Light System Manager, Video System Manager, Video System Manager Pro, iPlayer 3, Antumbra iColor Keypad, and ColorDial Pro, as well as third-party controllers.
